Aqua One EcoStyle Aquarium Filter Box and Filter Pump diagram

EcoStyle Filter Setup

Weekly Maintenance:

  1. Turn the power head off.
  2. Remove the lid from the filter unit.
  3. Remove the elbow and spray bar unit from the
    top of the power head.
  4. Remove the carbon cartridge and black filter
    sponge from the filter unit.
  5. Empty a small amount of water from the aquarium into a bucket.
  6. Rinse the black filter sponge in the bucket.
    Discard the used water; do not add it back into the
    aquarium.
  7. Rinse the carbon cartridge out under the tap, rinse thoroughly.
  8. Reinsert the carbon cartridge and black filter sponge.
  9. Then connect the elbow and spray bar unit back onto the outlet at the top of the power head.
  10. Ensure the aquarium is full.
  11. Turn the power head back on and ensure that water is flowing out of the spray bar.
  12. Close the lid on the aquarium.

The carbon filter cartridge should be replaced every 6 - 8 weeks for optimum filter performance.

Aqua One EcoStyle Aquarium Filter Box and Filter Pump diagram
Aqua One EcoStyle Aquarium  Filter Pump diagram

Filter Maintenance

Monthly Maintenance:

  1. Turn the power head off.
  2. Remove the lid from the filter unit.
  3. Remove the elbow and spray bar unit from the top of the power head.
  4. Remove the carbon cartridge and black filter sponge from the filter unit.
  5. Empty a small amount of water from the aquarium into a bucket.
  6. Rinse the black filter sponge in the bucket. Discard the used water; do not add it back into the aquarium.
  7. Rinse the carbon cartridge out under the tap, rinse thoroughly.
  8. Reinsert the carbon cartridge and black filter sponge.
  9. Then connect the elbow and spray bar unit back onto the outlet at the top of the power head.
  10. Ensure the aquarium is full.
  11. Turn the power head back on and ensure that water is flowing out of the spray bar.
  12. Close the lid on the aquarium.
  13. The carbon filter cartridge should be replaced every 6 - 8 weeks for optimum filter performance.

Aqua One EcoStyle Aquarium  Filter Pump diagram
Aqua One EcoStyle Aquarium  Filter Pump  powerhead to suit ecostyle 32 & 37

Filter Maintenance

Monthly

  1. Turn the power off. Unplug both power leads.
  2. Remove filter unit from aquarium, take to sink and open the lid.
  3. Disconnect spray bar and elbow and clean with double ended pipe brush.
  4. Lift the power head to remove from filter unit.
  5. Pull impeller cap off bottom of power head, this will uncover the impeller.
  6. Pull the impeller cap away from the power head.
  7. Grasp the impeller blades and remove from the impeller chamber.
  8. Use an Aqua One double ended pipe brush (sold separately) to clean the impeller and inside of impeller chamber.
  9. Also run a pipe brush through the outlet at the top of the power head.
  10. Clean the intake pipe and strainer thoroughly.
  11. Reconnect all parts and place filter unit back onto the aquarium.
  12. Ensure the power lead is not wet and plug it back in.
  13. Turn the power back on and check that water is flowing though the spray bar.
  14. Close the lid of the aquarium

Aqua One EcoStyle Aquarium  Filter Pump  powerhead to suit ecostyle 32 & 37

Aqua One EcoStyle Specifications

EcoStyle 32

Dimensions: 32 x 21 x 33cm
Aquarium Volume: 14L
Filter Flow Rate: 320l/hr
Light Wattage: 5W LED
Power Requirements: 220~240V
Suitable: Coldwater, Tropical

EcoStyle 37

Dimensions: 37 x 24 x 35cm
Aquarium Volume: 21L
Filter Flow Rate: 320l/hr
Light Wattage: 5W LED
Power Requirements: 220 ~ 240V
Suitable: Coldwater, Tropical

EcoStyle 42

Dimensions: 42 x 26 x 38cm
Aquarium Volume: 28L
Filter Flow Rate: 430l/hr
Light Wattage: 7W LED
Power Requirements: 220 ~ 240V
Suitable: Coldwater, Tropical

EcoStyle 47

Dimensions: 47 x 29 x 40cm
Aquarium Volume: 38L
Filter Flow Rate: 430l/hr
Light Wattage: 7W LED
Power Requirements: 220 ~ 240V
Suitable: Coldwater, Tropical

EcoStyle 61

Dimensions: 61 x 36 x 44cm
Aquarium Volume: 70L
Filter Flow Rate: 1100l/hr
Light Wattage: 10W LED
Power Requirements: 220 ~ 240V
Suitable: Coldwater, Tropical

EcoStyle 81

Dimensions: 81 x 41 x 53cm
Aquarium Volume: 127L
Filter Flow Rate: 1100l/hr
Light Wattage: 14W LED
Power Requirements: 220 ~ 240V
Suitable: Coldwater, Tropical

Trouble Shooting

Aqua One EcoStyle

LIGHT UNIT DOES NOT WORK
  1. Ensure switch is in the on position on the top of the light unit.
  2. Check light is plugged into power supply and the
    switch is on.
POWER HEAD WORKING BUT NO / SLOWWATER FLOW
  1. Check impeller is in good condition and replace if needed.
  2. Make sure water level in aquarium is above the power head. Please note the power head is a water proof unit.
  3. Clean impeller, power head and all inlet and outlet pipes.
  4. Check that the spray bar is inserted correctly with the end cap at the opposite end to the elbow

AQUARIUM POSSIBLY LEAKING
  1. Clean carbon cartridge as this can create an overflow.
  2. Make sure spray bar holes are pointed down onto the carbon cartridge.
  3. If an air stone is being used check it is not bubbling water over the rim of the aquarium if so turn the air pump down.
  4. Make sure the aquarium is sitting on a level surface.
  5. If it is a salt water aquarium remove any salt creep as it can drain water from the aquarium.
  6. Lift the lid and remove the filter unit from the top of the aquarium. Mark the water level. Remove any excess water that may be sitting on the edge of
    the aquarium. Leave for an hour.
  7. Remove the fish, decorations and gravel. Empty the aquarium and clean the glass DO NOT WASH
    IN SOAP OR DETERGENT. Place a piece of newspaper on a flat level solid surface. Carefully fill
    the aquarium ensuring not to spill any water on to the newspaper. Leave the aquarium for several hours and then inspect the newspaper for wet patches.
